| Composition | Lattice parameter (at 20oC) | Orientation | |
| GGG | Gd3Ga5O12 | 12.383 A +/- 0.001 | -111 -110 -100 |
| SGGG | Substituted GGG | 12.497 A +/- 0.003 | -111 -110 -100 |
| NGG | Nd3Ga5O12 | 12.509 A +/- 0.001 | -111 |
Standard diameters
GGG (Gd3Ga5O12) 1”, 2”, 3” or 4”
SGGG (Substituted GGG) 1”, 2”, 3” or 4”
NGG (Nd3Ga5O12) 1" or 2"
Available thicknesses
Any thickness > 450 microns
| Model | Dimensions | Tolerance | Orientation |
| GGG(001) 1"x0.5 | 1" diameter x 500 μm thick | Diameter: +/- 0.005” | Thickness: +/- 50 μm | Orientation: (001) +/- 0.1° |
| GGG(110) 1"x0.5 | 1" diameter x 500 μm thick | Diameter: +/- 0.005” | Thickness: +/- 50 μm | Orientation: (110) +/- 0.1° |
| GGG(111) 1"x0.5 | 1" diameter x 500 μm thick | Diameter: +/- 0.005” | Thickness: +/- 50 μm | Orientation: (111) +/- 0.1° |
| GGG(001) 2"x0.5 | 2" diameter x 500 μm thick | Diameter: +/- 0.005” | Thickness: +/- 50 μm | Orientation: (001) +/- 0.1° |
| GGG(110) 2"x0.5 | 2" diameter x 500 μm thick | Diameter: +/- 0.005” | Thickness: +/- 50 μm | Orientation: (110) +/- 0.1° |
| GGG(111) 2"x0.5 | 2" diameter x 500 μm thick | Diameter: +/- 0.005” | Thickness: +/- 50 μm | Orientation: (111) +/- 0.1° |
| GGG(001) 3"x0.5 | 3" diameter x 500 μm thick | Diameter: +/- 0.005” | Thickness: +/- 50 μm | Orientation: (001) +/- 0.1° |
| GGG(111) 3"x0.5 | 3" diameter x 500 μm thick | Diameter: +/- 0.005” | Thickness: +/- 50 μm | Orientation: (111) +/- 0.1° |
