    SS 104 A130-130短插头连接器Fischer

    发布时间：2024-11-22 09:20:10     浏览：501

    　　SS 104 A130-130是Fischer Connectors公司生产的一款高性能连接器，属于其Core系列中的104尺寸产品。这款连接器设计用于低电压信号或电源的传输，具有14个接触点，采用焊接方式进行端接，推拉式锁定系统便于连接和断开，且为线缆安装类型，适合需要频繁插拔的场合。外壳由黄铜制成，表面处理为灰色哑光，绝缘材料为高性能的PEEK，确保了产品的耐用性和可靠性。

    SS 104 A130-130短插头连接器Fischer

    　　产品名称: SS 104 A130-130

    　　系列: SS - SHORT PLUG(短插针)

    　　接触点数量: 14个

    　　连接器类型: 插头(Plug)

    　　端接类型: 焊接(Solder)

    　　锁定系统: 推拉式(Push-pull)

    　　安装类型: 线缆安装(Cable Mounted)

    　　信号/电源: 低电压(Low Voltage)

    　　外壳材料: 黄铜(Brass)

    　　外壳颜色: 灰色哑光(Grey Mat)

    　　绝缘材料: PEEK(聚醚醚酮)

    　　相关型号参数：

    ConnectorContactsTermination typeLocking systemSignal / PowerSealing level
    SS 104 A130-13014Solder  Push-pull
    		   IP50
    143227   Low Voltage
    SS 104 A131-13012Solder  Push-pull   Low Voltage   IP50
    143222
    SS 1031 A015-13015Solder  Push-pull   LowVoltage   IP50
    142813
    SS 103 A015-600-C424881Solder  Push-pull   Triax   IP50
    142499
    SS 103 A058-1508Crimp  Push-pull   LowVoltage   IP50

    138771
    AL1731-SS-105-A102CP11-1327Crimp  Push-pull   Low Voltage   IP50
    136564
    AL1731-SS-104-A040CP11-133Crimp  Push-pull   Low Voltage   IP50
    135658
    SS 105 Z067-1308Solder  Push-pull   Low Voltage   IP50
    135558
    SS 103 Z058-1508Crimp  Push-pul   Low Voltage   IP50
    135260
    AL1731-SS-103-A057CP11-137Crimp  Push-pull   LowVoltage   IP50
    138768
    SS 103 Z053-1304Solder  Push-pull   Low Voltage   IP50
    130546
    AL1731-SS-103-A062SR11-1312Solder  Push-pul   Low Voltage   IP50
    130163
    SS 105 Z062-13010Solder  Push-pull   Low Voltage   IP50
    129212
    SS 105 z052-1303Solder  Push-pull   LowVoltage   IP50
    129124
    SS 104 Z040-803Solder  Push-pull   LowVoltage   IP50
    127519
    SS 104 A104-13012Solder  Push-pul   Low Voltage   IP50
    142766
    SS 102 Z052-1303Solder  Push-pull   Low Voltage   IP50
    108456
    AL1731-SS-105-A053SR11-134Solder  Push-pull   Low Voltage   IP50
    124174
    SS 105 A102-15027Crimp  Push-pull   Low Voltage   IP50
    108803
    SS 102 Z051-1302Solder  Push-pull   LowVoltage   IP50
    108092
    SS 104 Z037-1304Solder  Push-pul   Low Voltage   IP50
    120223
    SS 104 A051-1302Solder  Push-pul   Low Voltage   IP50
    112949
    SS 105 Z054-1307Solder  Push-pull   Low Voltage   IP50
    128466
    SS 103 Z057-1307Solder  Push-pull   Low Voltage   IP50
    107971
    SS 102 Z056-1507Crimp  Push-pull   LowVoltage   IP50
    120672
    SS 103 A057-1307Solder  Push-pull   Low Voltage   IP50
    107732
    SS 1031 A105-13014Solder  Push-pul   Low Voltage   IP50
    143217
     SS 104 Z066-1308SolderPush-pullLow VoltageIP50
    104014
     SS 103 Z058-1308SolderPush-pulLow VoltageIP50
    107957
     SS 104 Z092-13019SolderPush-pullLow VoltageIP50
    118916
     SS 104 Z087-804SolderPush-pulLowVoltageIP50
    104009
     SS 104 A124-15027CrimpPush-pulLow VoltageIP50
    108863
     SS 104 Z053-1305SolderPush-pullLow VoltageIP50
    104006
     SS 103 Z052-1303SolderPush-pulLow VoltageIP50
    125924
     SS 105 A069-13012SolderPush-pulLow VoltageIP50
    121013
     SS 103 A058-1308SolderPush-pullLow VoltageIP50
    107959
     SS 1031Z010-15010CrimpPush-pulLowVoltageIP50
    102527
     SS 104 A087-804SolderPush-pullLow VoltageIP50
    103635
     SS 1031 A010-13010SolderPush-pullLow VoltageIP50
    102368
     SS 1031Z010-13010SolderPush-pulLow VoltageIP50
    102537
     SS 105 A104-13013SolderPush-pullLow VoltageIP50
    131124
     AL1731-SS-1031-A019SR11-1319SolderPush-pullLowVoltageIP50
    127319
     SS 1031 A010-15010CrimpPush-pulLowVoltageIP50
    102442
     SS 1031 A019-15019CrimpPush-pullLow VoltageIP50
    102426
     SS 1031Z019-13019SolderPush-pulLow VoltageIP50
    107763
     AL1731-SS-104-A092SR11-1419SolderPush-pullLow VoltageIP50
    133960
     SS 104 A054-1307SolderPush-pullLowVoltageIP50
    119981
     SS 102 A053-1504CrimpPush-pulLowVoltageIP50
    100914
     SS 102 A051-1302SolderPush-pulLow VoltageIP50
    114106
     SS 102 Z054-1305SolderPush-pullLow VoltageIP50
    101220
     SS 105 A038-15018CrimpPush-pulLow VoltageIP50
    114024
     SS 103 Z056-1506CrimpPush-pullLow VoltageIP50
    102165
     SS 105 A067-1308SolderPush-pullLow VoltageIP50
    106528
     SS 104 Z056-13011SolderPush-pulLowVoltageIP50
    106483
     SS 1031 A012-13012SolderPush-pullLow VoltageIP50
    102407
     SS 102 A056-1507CrimpPush-pulLow VoltageIP50
    100982
     AL1731-SS-103-Z051SR11-142SolderPush-pulLow VoltageIP50
    133958
     SS 103 A062-13012SolderPush-pullLowVoltageIP50
    101865
     SS 104 A037-1504CrimpPush-pulLowVoltageIP50
    135261
     SS 103 A053-1304SolderPush-pullLow VoltageIP50
    115152
     SS 102 A054-1305SolderPush-pullLow VoltageIP50
    100897
     SS 105 Z069-13012SolderPush-pulLow VoltageIP50
    132302
     SS 104 Z055-1309SolderPush-pullLow VoltageIP50
    114770
     SS 105 A062-13010SolderPush-pullLow VoltageIP50
    128346
     SS 103 A051-1302SolderPush-pulLow VoltageIP50
    101877
     SS 1031 A012-15012              Crimp  Push-pullLow VoltageIP50
    102463
     SS 105 A093-8024Solder  Push-pullLow VoltageIP50
    123972
     SS 102 A056-1307Solder  Push-pullLow VoltageIP50
    100888
     SS 105 Z093-8024Solder  Push-pullLow VoltageIP50
    119636
     AL1731-SS-103-A054CP11-135CrimpPush-pullLow VoltageIP50
    131226
     SS 102 A053-1304Solder  Push-pullLow VoltageIP50
    100901
     SS 1031 A019-13019Solder  Push-pullLow VoltageIP50
    102423
     SS 104 A056-13011Solder  Push-pullLow VoltageIP50
    103563
     SS 104 A040-803Solder  Push-pullLow VoltageIP50
    125055
     SS 103 A054-1305Solder  Push-pullLow VoltageIP50
    101878
     SS 103 Z054-1305Solder  Push-pullLow VoltageIP50
    102176
     SS 104 A092-13019Solder  Push-pullLow VoltageIP50
    107949
     AL1731-SS-102-Z051SR11-132Solder  Push-pullLow VoltageIP50
    125995
     SS 102 Z053-1304Solder  Push-pullLow VoltageIP50
    101230
     SS 105 Z102-15027CrimpPush-pulLow VoltageIP50
    137515
     SS 104 Z053-1505Crimp  Push-pullLow VoltageIP50
    108520
     AL1731-SS-102-A054SR11-135Solder  Push-pullLow VoltageIP50
    121134
     SS 103 A052-1303Solder  Push-pullLow VoltageIP50
    101907
     SS 105 A102-13027Solder  Push-pullLow VoltageIP50
    113051
     SS 102 Z056-1307Solder  Push-pullLow VoltageIP50
    113078
     AL1731-SS-102-A056SR11-137Solder  Push-pullLow VoltageIP50
    113189
     SS 105 Z110-13016Solder  Push-pullLow VoltageIP50
    129308
     SS 103 Z056-1306Solder  Push-pullLow VoltageIP50
    113991
     SS 103 A062-16012Crimp  Push-pullLow VoltageIP50
    113388
     SS 104 A086-13016Solder  Push-pullLow VoltageIP50
    113409
     SS 104 A055-1309Solder  Push-pullLow VoltageIP50
    114771
     SS 102 A066-1302Solder  Push-pullLow VoltageIP50
    140901
     SS 1031Z012-13012Solder  Push-pullLow VoltageIP50
    113992
     SS 102 Z054-1505Crimp  Push-pullLow VoltageIP50
    114107
     AL1231-SS-103-A062CP11-1312Crimp  Push-pullLow VoltageIP50
    114145
     SS 1031Z019-15019Crimp  Push-pullLow VoltageIP50
    114240
     SS 105 Z058-13015Solder  Push-pullLow VoltageIP50
    127137
     AL1731-SS-102-A052SR11-133Solder  Push-pullLow VoltageIP50
    114200
     SS 103 Z051-1302Solder  Push-pullLow VoltageIP50
    116260
     SS 102 A059-1309Solder  Push-pullLow VoltageIP50
    114037
     SS 102 A054-1505Crimp  Push-pullLow VoltageIP50
    125382
     SS 104 A066-1308Solder  Push-pullLow VoltageIP50
    103648
     SS 104 Z086-13016Solder  Push-pullLow VoltageIP50
    116384
     SS 104 A053-1305SolderPush-pullLow VoltageIP50
    116669
    SS 105 A058-13015  Solder  Push-pull  Low Voltage  IP50
    116670
    SS 1031 A029-13012  Solder  Push-pull  Low Voltage  IP50
    142781
    SS 102 Z053-1504  Crimp  Push-pul  Low Voltage  IP50
    101207
    SS 104 A037-1304  Solder  Push-pul  Low Voltage  IP50
    116725
    SS 104 A065-1306  Solder  Push-pul  Low Voltage  IP50
    116964
    SS 104 Z065-1306  Solder  Push-pull  Low Voltage  IP50
    116965
    AL1731-SS-103-A053SR11-144  Solder  Push-pul  Low Voltage  IP50
    121043
    SS 105 A087-1302  Solder  Push-pull  Low Voltage  IP50
    116999
    SS 105 Z087-1302  Solder  Push-pul  Low Voltage  IP50
    117087
    SS 104 Z051-1302  Solder  Push-pul  Low Voltage  IP50
    134242
    SS 102 Z059-1309  Solder  Push-pull  Low Voltage  IP50
    118924
    AL1731-SS-104-A066CP11-138  Crimp  Push-pul  Low Voltage  IP50
    136577
    SS 105 Z102-13027  Solder  Push-pul  Low Voltage  IP50
    119798
    SS 105 Z053-1304  Solder  Push-pul  Low Voltage  IP50
    120071
    AL1731-SS-1031-A010SR11-1310  Solder  Push-pull  Low Voltage  IP50
    126511
    AL1731-SS-102-A051SR11-132  Solder  Push-pul  Low Voltage  IP50
    121132
    SS 102 A051-1502  Crimp  Push-pul  Low Voltage  IP50
    106286
    SS 105 A053-1304  Solder  Push-pul  Low Voltage  IP50
    120815
    SS 103 A056-1306  Solder  Push-pull  Low Voltage  IP50
    101870
    SS 1031 Z012-15012  Crimp  Push-pul  Low Voltage  IP50
    123957
    SS 102 A052-1303  Solder  Push-pull  Low Voltage  IP50
    100890
    AL1731-SS-105-A093SR11-1324  Solder  Push-pul  Low Voltage  IP50
    124175
    AL1731-SS-1031-A012SR11-1312  Solder  Push-pull  Low Voltage  IP50
    126512
    SS 105 A110-13016  Solder  Push-pull  Low Voltage  IP50
    105020
    SS 105 A038-13018  Solder  Push-pul  LowVoltage  IP50
    125917
    SS 105 A124-1308  Solder  Push-pul  Low Voltage  IP50
    125139
    SS 105 A062-15010  Crimp  Push-pul  Low Voltage  IP50
    126184
