Lattice LC4256V-75TN176C复杂可编程逻辑器件(CPLD)
发布时间：2024-09-11 09:25:56 浏览：635
Lattice半导体公司推出的LC4256V-75TN176C是一款高性能的复杂可编程逻辑器件(CPLD)，属于ispMACH
4000V/B家族，符合RoHS标准，确?；肪秤押?。该产品设计精良，旨在满足现代工业控制和通信系统对性能和可靠性的高要求。
系统属性
该CPLD包含16个逻辑?？?，提供4个全局时钟和2个I/O Bank。其程序存储类型为EEPROM，内置防振器，确保数据的安全性和稳定性。
软/硬件规格
LC4256V-75TN176C拥有256个论坛宏DB包含数，80个宏单元和576个寄存器。最大用户I/O数达到128，支持在线系统编程和可重编程性。其最大频率为168
MHz，最大时钟到输出延迟为4.5 ns，最大地传送延迟为7.5 ns，速度等级为75，且受时间抖动控制。
电气参数
该产品支持的最大工作电源电压为3.6 V，最小为3 V，额定工作电源电压为3.3 V。静态功耗电值为5 mA，最大工作重点电流为12.5
mA。
环境/机械特性
LC4256V-75TN176C的最低工作温度为0℃，最高工作温度为90℃，适应多种环境条件。
包装信息
该CPLD采用商业供应链，封装形式为托盘，商名为ispMACH 4000。安装方式为表面焊装，包装尺寸为宽度14 mm，高度2.4 mm，长度24
mm。引线数目为176，PCB散热采用QFP塑，封装验证为TQFP验证，引脚数为176，引线形状为扁平型。
LC4256V-75TN176C
CPLD以其卓越的性能和可靠性，成为工业控制和通信系统等领域的理想选择。其灵活的编程能力和稳定的运行特性，确保了系统的高效运行和长期稳定性。
相关型号：
| Device | Part Number | Macrocells | Voltage | tpD | Package | Pin/Ball Count | /O | Grade |
| LC4256V | LC4256V-3FT256AC | 256 | 3.3 | 3 | ftBGA | 256 | 128 | C |
| LC4256V-5FT256AC | 256 | 3.3 | 5 | ftBGA | 256 | 128 | C |
| LC4256V-75FT256AC | 256 | 3.3 | 7.5 | ftBGA | 256 | 128 | C |
| LC4256W-3FT256BC | 256 | 3.3 | 3 | ftBGA | 256 | 160 | C |
| LC4256V-5FT256BC | 256 | 3.3 | 5 | ftBGA | 256 | 160 | C |
| LC4256V-75FT256BC | 256 | 3.3 | 7.5 | ftBGA | 256 | 160 | C |
| LC4256V-3F256AC1 | 256 | 3.3 | 3 | fpBGA | 256 | 128 | C |
| LC4256V-5F256AC | 256 | 3.3 | 5 | fpBGA | 256 | 128 | C |
| LC4256V-75F256AC | 256 | 3.3 | 7.5 | fpBGA | 256 | 128 | C |
| LC4256W-3F256BC | 256 | 3.3 | 3 | fpBGA | 256 | 160 | C |
| LC4256W-5F256BC | 256 | 3.3 | 5 | fpBGA | 256 | 160 | C |
| LC4256V-75F256BC1 | 256 | 3.3 | 7.5 | fpBGA | 256 | 160 | C |
| LC4256V-3T176C | 256 | 3.3 | 3 | TQFP | 176 | 128 | C |
| LC4256V-5T176C | 256 | 3.3 | 5 | TQFP | 176 | 128 | C |
| LC4256V-75T176C | 256 | 3.3 | 7.5 | TQFP | 176 | 128 | C |
| LC4256W-3T144C | 256 | 3.3 | 3 | TQFP | 144 | 96 | C |
| LC4256V-5T144C | 256 | 3.3 | 5 | TQFP | 144 | 96 | C |
| LC4256V-75T144C | 256 | 3.3 | 7.5 | TQFP | 144 | 96 | C |
| LC4256V-3T100C | 256 | 3.3 | 3 | TQFP | 100 | 64 | C |
| LC4256V-5T100C | 256 | 3.3 | 5 | TQFP | 100 | 64 | C |
| LC4256V-75T100C | 256 | 3.3 | 7.5 | TQFP | 100 | 64 | C |
| LC4256V | LC4256V-5FT256AI | 256 | 3.3 | 5 | ftBGA | 256 | 128 | I |
| LC4256V-75FT256Al | 256 | 3.3 | 7.5 | ftBGA | 256 | 128 | I |
| LC4256Y-10FT256Al | 256 | 3.3 | 10 | ftBGA | 256 | 128 | I |
| LC4256V-5FT256B | 256 | 3.3 | 5 | ftBGA | 256 | 160 | I |
| LC4256V-75FT256BI | 256 | 3.3 | 7.5 | ftBGA | 256 | 160 | I |
| LC4256V-10FT256BI | 256 | 3.3 | 10 | ftBGA | 256 | 160 | I |
| LC4256W-5F256Al | 256 | 3.3 | 5 | fpBGA | 256 | 128 | I |
| LC4256V-75F256AI | 256 | 3.3 | 7.5 | fpBGA | 256 | 128 | I |
| LC4256W-10F256AI | 256 | 3.3 | 10 | fpBGA | 256 | 128 | I |
| LC4256W-5F256BI | 256 | 3.3 | 5 | fpBGA | 256 | 160 | I |
| LC4256V-75F256BI1 | 256 | 3.3 | 7.5 | fpBGA | 256 | 160 | I |
| LC4256V-10F256BI | 256 | 3.3 | 10 | fpBGA | 256 | 160 | I |
| LC4256V-5T176I | 256 | 3.3 | 5 | TQFP | 176 | 128 | I |
| LC4256V-75T176I | 256 | 3.3 | 7.5 | TQFP | 176 | 128 | I |
| LC4256Y-10T176I | 256 | 3.3 | 10 | TQFP | 176 | 128 | I |
| LC4256W-5T1441 | 256 | 3.3 | 5 | TQFP | 144 | 96 | I |
| LC4256Y-75T144I | 256 | 3.3 | 7.5 | TQFP | 144 | 96 | I |
| LC4256V-10T144I | 256 | 3.3 | 10 | TQFP | 144 | 96 | I |
| LC4256W-5T100I | 256 | 3.3 | 5 | TQFP | 100 | 64 | I |
| LC42568-75T100I | 256 | 3.3 | 7.5 | TQFP | 100 | 64 | I |
| LC4256V-10T100I | 256 | 3.3 | 10 | TQFP | 100 | 64 | I |
| LC4256V | LC4256W-75T176E | 256 | 3.3 | 7.5 | TQFP | 176 | 128 | E |
| LC4256W-75T144E | 256 | 3.3 | 7.5 | TQFP | 144 | 96 | E |
| LC4256V-75T100E | 256 | 3.3 | 7.5 | TQFP | 100 | 64 | E |
| LC4256V | C4256V-3FTN256AC | 256 | 3.3 | 3 | Lead-free ftBGA | 256 | 128 | C |
| LC4256V-5FTN256AC | 256 | 3.3 | 5 | Lead-free ftBGA | 256 | 128 | C |
| LC4256V-75FTN256AC | 256 | 3.3 | 7.5 | Lead-free ftBGA | 256 | 128 | C |
| LC4256V-3FTN256BC | 256 | 3.3 | 3 | Lead-free ftBGA | 256 | 160 | C |
| LC4256V-5FTN256BC | 256 | 3.3 | 5 | Lead-free ftBGA | 256 | 160 | C |
| LC4256V-75FTN256BC | 256 | 3.3 | 7.5 | Lead-free ftBGA | 256 | 160 | C |
| LC4256V-3FN256AC | 256 | 3.3 | 3 | Lead-free fpBGA | 256 | 128 | C |
| LC4256V-5FN256AC | 256 | 3.3 | 5 | Lead-free fpBGA | 256 | 128 | C |
| LC4256V-75FN256AC1 | 256 | 3.3 | 7.5 | Lead-free fpBGA | 256 | 128 | C |
| LC4256V-3FN256BC | 256 | 3.3 | 3 | Lead-free fpBGA | 256 | 160 | C |
| LC4256V-5FN256BC1 | 256 | 3.3 | 5 | Lead-free fpBGA | 256 | 160 | C |
| LC4256V-75FN256BC | 256 | 3.3 | 7.5 | Lead-free fpBGA | 256 | 160 | C |
| LC4256V-3TN176C | 256 | 3.3 | 3 | Lead-free TOFP | 176 | 128 | C |
| LC4256V-5TN176C | 256 | 3.3 | 5 | Lead-free TQFP | 176 | 128 | C |
| LC4256V-75TN176C | 256 | 3.3 | 7.5 | Lead-free TOFP | 176 | 128 | C |
| LC4256V-3TN144C | 256 | 3.3 | 3 | Lead-free TQFP | 144 | 96 | C |
| LC4256V-5TN144C | 256 | 3.3 | 5 | Lead-free TQFP | 144 | 96 | C |
| LC4256V-75TN144C | 256 | 3.3 | 7.5 | Lead-free TQFP | 144 | 96 | C |
| LC4256V-3TN100C | 256 | 3.3 | 3 | Lead-free TQFP | 100 | 64 | C |
| LC4256V-5TN100C | 256 | 3.3 | 5 | Lead-free TQFP | 100 | 64 | C |
| LC4256V-75TN100C | 256 | 3.3 | 7.5 | Lead-free TQFP | 100 | 64 | C |
